I51BE240F10V10000S / i510-C4/400-3 / 4 kW/5 HP / 16270390
| Material number |
16270390 |
| Inverter product series |
i510 Frequency inverter |
| Inverter |
i510-C4/400-3 |
| Type |
I51BE240F10V10000S |
| Axes |
S |
| Rated power |
4 kW/5 HP |
| Rated power LD |
5.5 kW/7.5 HP |
| Rated mains voltage |
3/PE 400/480 V AC |
| Output current |
9.5/8.2 A |
| Output current LD |
11.9/9.8 A |
| Output frequency |
0-599 Hz |
| I/O extension |
Basic I/O |
| Fieldbus network |
Without |
| Functional safety |
Without |
| Motor encoder |
Without |
| Enclosure |
IP20 |
| Mounting location |
Control cabinet |
| Mounting type |
On mounting plate |
| Mot power |
5.00 HP |
| Degree of protection spec. |
IP20 |
| Generation |
B |
| Mot power |
4.00 kW |
| Application area (geographic) |
EU |
| Weight |
1.66 KG |
